2024. 4. 18. 15:40 Unity/C#







https://ahzkwid.booth.pm/items/5632873



Automatic Shadow Distance - Wmup - BOOTH

ワールド用です DirectionalLightの影の長さをFPSに応じて自動的に変更するツールです。 動きがきれいじゃないので、キャラクターシャドウ専用に使用するのをお勧めします - Code - https://gist.githu

ahzkwid.booth.pm

여기서 다운 가능











using UdonSharp;
using UnityEngine;
using UnityEngine.UI;
using VRC.SDKBase;
using VRC.Udon;

[UdonBehaviourSyncMode(BehaviourSyncMode.None)]
public class AutomaticShadowDistance : UdonSharpBehaviour
{
    public Light directionalLight;
    public float frameCheckTimeCycle = 3f;
    int playerLayerIndex = 9;
    public Vector2 targetFps = new Vector2(30, 60);
    public Vector2 defaultShadowDistance = new Vector2(10, 80);
    public Vector2 playerShadowDistance = new Vector2(1,15);

    float tPre = 2;

    void UpdateShadowDistance(float t)
    {
        var defaultShadowDistanceMin = defaultShadowDistance.x;
        var defaultShadowDistanceMax = defaultShadowDistance.y;
        var playerShadowDistanceMin = playerShadowDistance.x;
        var playerShadowDistanceMax = playerShadowDistance.y;


        var targetDistanceDefault = Mathf.Lerp(defaultShadowDistanceMin, defaultShadowDistanceMax, t);
        var targetDistancePlayer = Mathf.Lerp(playerShadowDistanceMin, playerShadowDistanceMax, t);

        {
            //QualitySettings.shadowDistance = targetDistanceDefault;
        }
        {
            var ShadowCullDistances = new float[32];
            //ShadowCullDistances[0] = Mathf.Lerp(ShadowCullDistances[0], targetDistanceDefault, 0.1f);
            ShadowCullDistances[0] = targetDistanceDefault;
            ShadowCullDistances[11] = ShadowCullDistances[0];
            ShadowCullDistances[13] = ShadowCullDistances[0];
            ShadowCullDistances[14] = ShadowCullDistances[0];
            ShadowCullDistances[playerLayerIndex] = targetDistancePlayer;
            ShadowCullDistances[10] = ShadowCullDistances[playerLayerIndex];
            ShadowCullDistances[18] = ShadowCullDistances[playerLayerIndex];
            directionalLight.layerShadowCullDistances = ShadowCullDistances;

            //Camera.main.layerCullDistances = ShadowCullDistances;
        }
    }

    LightShadows shadowType = LightShadows.Soft;
    void Start()
    {
        //if (directionalLight==null)
        //{
        //    /*
        //    var lights = FindObjectsOfType<Light>();
        //    foreach (var light in lights)
        //    {
        //        if (light.type==LightType.Directional)
        //        {
        //            directionalLight = light;
        //        }
        //    }
        //    */
        //    /*
        //    var light= FindObjectOfType<Light>();
        //    if (light.type == LightType.Directional)
        //    {
        //        directionalLight = light;
        //    }
        //    */
        //}
        if (directionalLight.shadows != LightShadows.None)
        {
            shadowType = directionalLight.shadows;
        }

        UpdateShadowDistance(0);

        lastCheckTime = 0;
    }
    float lastCheckTime = 0;
    int frameCount = 0;

    public Toggle toggle;
    public Slider slider;
    public GameObject lockPanel;

    public bool alwaysUseShdow = true;
    bool CheckT(float t)
    {
        return ((Mathf.Abs(t - tPre) > 0.1f)
            || ((t == 0) && (tPre < 0.1f))
            || ((t == 1) && (tPre > 0.9f)));
    }
    void Update()
    {
        var useShadowOff = !alwaysUseShdow;

        var toggleManual = toggle;
        lockPanel.SetActive(toggleManual.isOn == false);



        var useShadowOffvalue = 0.1f;
        if (toggleManual.isOn)
        {
            if (slider.value > useShadowOffvalue)
            {
                var t = (slider.value - useShadowOffvalue) * (1f / (1f- useShadowOffvalue));
                if (CheckT(t))
                {
                    UpdateShadowDistance(t);
                    tPre = t;
                }
                if (useShadowOff)
                {
                    if (directionalLight.shadows == LightShadows.None)
                    {
                        directionalLight.shadows = shadowType;
                    }
                }
            }
            else
            {
                if (useShadowOff)
                {
                    if (directionalLight.shadows != LightShadows.None)
                    {
                        directionalLight.shadows = LightShadows.None;
                    }
                }
            }
        }
        else
        {


            frameCount++;

            if (Time.time - lastCheckTime >= frameCheckTimeCycle)
            {
                var fps = 0f;
                if (Time.deltaTime > 0)
                {
                    fps = 1f / Time.deltaTime;
                }
                if (frameCheckTimeCycle > 0.1f)
                {
                    fps = frameCount / frameCheckTimeCycle;
                }


                var min = targetFps.x;
                var max = targetFps.y;
                var t = (Mathf.Clamp(fps, min, max) - min) / (max - min);

                /*
                if ((Mathf.Abs(t - tPre) > 0.1f)
                    || ((t == 0) && (tPre < 0.1f))
                    || ((t == 1) && (tPre > 0.9f)))
                */
                if (CheckT(t))
                {

                    UpdateShadowDistance(t);
                    tPre = t;

                }


                if (Time.time > 10)
                {
                    if (useShadowOff)
                    {
                        if (directionalLight.shadows == LightShadows.None)
                        {
                            if (t > 0.8f)
                            {
                                directionalLight.shadows = shadowType;
                            }
                        }
                        else
                        {
                            if (fps < min / 2)
                            {
                                directionalLight.shadows = LightShadows.None;
                            }
                        }
                    }
                }
                if (directionalLight.shadows == LightShadows.None)
                {
                    slider.value = 0f;
                }
                else
                {
                    slider.value = useShadowOffvalue + t * (1f- useShadowOffvalue);
                }


                frameCount = 0;
                lastCheckTime = Time.time;
            }
        }
    }
}

'Unity > C#' 카테고리의 다른 글

c# Dictionary(딕셔너리) 관련  (0) 2024.03.19
자주 쓰는 DateTime 코드 모음  (0) 2023.12.19
Path 연산  (0) 2023.09.09
posted by 모카쨩
2024. 4. 18. 12:01 이 세계의 법칙



인간이 미개해서 존재했던게 아니다.

사랑하는 사람이 반려동물을 잃고 저세상에서라도 다시 만날수 있겠지?라고 슬피 우는데

그 누가 잔혹한 현실을 말할수 있을까?

이런 거짓말들이 모여 탄생한 동화인것이다

'이 세계의 법칙' 카테고리의 다른 글

전생은 가능할까?  (0) 2023.12.28
중첩현상이 발생하는이유  (0) 2023.11.25
종교의 탄생  (0) 2022.12.19
posted by 모카쨩
2024. 4. 16. 23:27 Unity







에셋을 팔다보니 내가 만든 툴들 동봉해야 하는경우 많았는데 버전충돌 방지하려고 서로 다른 네임스페이스 넣는건 좋았는데 하나하나 일일히 넣으려니 ㅈㄴ 귀찮았다









이렇게 하면 파일별로 네임스페이스 수정 안 하고 저거 두개만 수정하면 된다







'Unity' 카테고리의 다른 글

게임개발용 부하테스트 2024  (0) 2024.02.27
텍스처 메모리와 성능과의 연관성  (0) 2024.02.27
유니티 모델 임포트 에러  (0) 2024.02.24
posted by 모카쨩
2024. 4. 16. 18:14 나의 작은 정보들




https://twitter.com/ahzkwid/status/1724202667294282118



화력발전소 송전단 열효율 38%에 송변전 손실 4% 감안하면

약 36.5%니까 단순계산으로 가스요금보다 2.74배 높아야 하니까

가스비 8만원 나오는 사람이면 22만원 나온다는 결론이 나옴.



참고로 전기에너지를 열에너지로 바꾸는 효율은 99%에 근접해서 에너지 소비 효율을 따로 붙이지 않는다
